LEMO launches single pair ethernet 1000BASE–T1

Take heed to this text

Voiced by Amazon Polly

As community necessities have modified over time, ethernet has persistently improved by way of pace, safety, and high quality. In consequence, it has emerged as the usual for wired connectivity in most industries, together with IT, telecommunications, transportation, and protection. The expansion of ethernet in each industrial automation and the auto trade is at the moment being accelerated by the emergence of Single Pair Ethernet (SPE).

Following this growth, LEMO has offered options over time which can be compliant with the varied ethernet protocols as they emerged. In consequence, it has one of the intensive portfolios of connectors for high-speed ethernet as much as 10 Gb/s and has just lately added options for SPE. LEMO Single Pair Ethernet (SPE) 1000Base-T1 is designed to function over a single twisted-pair copper cable supporting an efficient knowledge fee of 1 Gb/sec in each instructions concurrently. These merchandise had been designed particularly to carry out in harsh environments (resembling extreme humidity, vibration, or excessive temperatures) for quite a lot of purposes.

For Unshielded Twisted Pair (UTP) and Shielded Twisted Pair (STP), LEMO affords two sorts of insulators: 0B.511 (2 contacts) and 1B.512(4 contacts + display screen). The brand new product can also be supplied in a watertight model for the T collection connector.

Deciding on an SPE connector doesn’t robotically assure compliance with this protocol and the associated knowledge switch pace for the entire interconnect answer. The truth is, the cables should no less than adjust to the identical protocol, respect the utmost size given within the protocol, and be rigorously assembled to the connector; the answer should be totally examined. LEMO’s consultants are prepared to help you with compliant high-speed Interconnect options, please be happy to succeed in out.

LEMO Single Pair Ethernet (SPE) 1000BASE-T1 key options:

  • Push-pull latching mechanism allows speedy, easy, protected, and dependable frequent join and disconnect
  • Shield delicate knowledge in harsh environments with a proprietary interface
  • The IEEE 802.3bp (SPE) protocol compliance and assured sign integrity permit knowledge switch at charges as much as 1Gb/s.
  • 360° screening for full EMC shielding
  • Appropriate with unshielded twisted pair (UTP) and shielded twisted pair (STP)
  • As much as 5000 assured mating cycles, leading to elevated service life and diminished possession prices
  • A variety of sturdy and miniature fashions (together with IP50, IP66, and IP68) present ruggedized compact integrations
  • Temperature vary -55 °C to 250 °C
  • As much as 12 keyways for alignment
